Данные о продукции
| NA | 0.4 |
| ДФ | 1.7 μm |
| Исправленная длина волны | 480-1800 nm |
| Масса | 305 g |
| Поле зрения 1 | ø1.2 mm |
| Поле зрения 2 | 0,24 x 0,32 mm |
| Р | 0.7 µm |
| Рабочее расстояние | Through glass: 20.35 mmIn Air: 19.98 mm |
| Сокращения в таблице продуктов | N.A.: Numerical apertureW.D.: Working distanceP.D.: Parfocal distancef: Focal distanceR: Resolving powerD.F.: Depth of focusFOV 1: Field of view when using ø24 mm eyepieceFOV 2: Field of view when using a digital camera with 1/2" chip size |
| Увеличение | 20x |
| ф | 10 mm |
| Функции | Near-infrared wavelength and LCD Glass Thickness CorrectedLCD Plan Apo NIR for Bright Field ObservationCompatible with microscope types VMU / FS-70Note: W.D. is just measured in air, not through an LCD glass |
