Данные о продукции
| M План Апо NIR | Note: These objective lenses are designed so that the image of a workpiece remains focused within the focal depth even when the wavelength used is changed from within the visible range up to the near-infrared (480 to 1,800 nm).Therefore the M Plan NIR Series are suitable for laser repair. However, when the wavelength used exceeds 1,100 nm, the focussing position may deviate slightly from that in the visible range due to changes in glass dispersion and refractive index. |
| NA | 0.42 |
| ДФ | 1.6 μm |
| Исправленная длина волны | 480-1800 nm |
| ПД | 95 mm |
| Поле зрения 1 | ø0.48 mm |
| Поле зрения 2 | 0,1 x 0,13 mm |
| Р | 0.7 µm |
| Рабочее расстояние | In Air: 17 mm |
| Сокращения в таблице продуктов | N.A.: Numerical apertureW.D.: Working distanceP.D.: Parfocal distancef: Focal distanceR: Resolving powerD.F.: Depth of fieldFOV 1: Field of view when using ø24 mm eyepieceFOV 2: Field of view when using a digital camera with 1/2" chip size |
| Увеличение | 50x |
| ф | 4 mm |
| Функции | Near-infrared wavelength CorrectedM Plan Apo NIR for Bright Field ObservationCompatible with microscope types VMU / FS-70 |
