Данные о продукции
| Бумага для принтера | Width: 58 mm, length: 48 m |
| Ввод данных | Digimatic, Digimatic 2, RS-232C Input (KA-Counter only) |
| Вывод данных | USB, RS-232C at TTL level, tolerance judgment result (-NG, GO, +NG) |
| Доставленный | Including AC-Adapter, printer paper (1 roll), carrying strap |
| Источник питания | AC adapter 6V, battery: LR6 x 4 (alkaline) or AA x 4 Ni-MH (rechargeable, battery is not charged in the device) |
| Масса | 390 g |
| Мощность переработки | Mode 0: 100,000 data entriesMode 1/2: 9,999 data entriesMode 3: sample size 10x subgroup 9,999= total number of data entries 99,990 |
| Номер строки принтера | 7,000 lines/roll (with large font)10,000 lines/roll (with normal font) |
| Печатные данные | Measurement data, GO/±NO GO judgement, number of data, maximum/minimum value, range, average, standard deviation, number of defective, fraction defective, process capability, index, histogram, D-chart, control chart, generation for Xd-bar and control limit data, date and time |
| Регистрация данных измерений (для хранения) | Max. 1000 points |
| Скорость печати принтера | 6.5 mm/s (using AC adapter) |
| Срок службы батареи | Appr. 10000 lines (with 1600 mA Ni-MH and print 1 time/5 s) |
| Тип принтера | Thermal line printer |
| Функция таймера | 0.25 s; 1 s; 5 s; 30 s; 1 min; 30 min; 60 min(0.25 s only statistical function) |
