Данные о продукции
| Вес загрузки | 300 kg |
| Диапазон | 800 µm; 80 µm; 8 µm(bis zu 2,4 mm mit einem optionalen Taster) |
| Диапазон наклона | -45° (CCW) to +10° (CW) |
| Измерение скорости | 0.02 - 2 mm/s |
| Программное обеспечение | FORMTRACEPAK• Enables control of all axes for realizing efficient measurement automation. • Perform contour evaluation that allows free analysis of level differences, angles, pitch, area and other characteristics as well as surface roughness evaluation. • Able to create an original inspection certificate by setting the print format to suit particular requirements. |
| Профили | Primary Profile (P), Roughness Profile (R), Waviness (W), MOTIF (R, W) and more |
| Прямолинейность траверса | X = 0.5 µm / 200 mm (standard)X = 0.7 µm / 200 mm(long-type detector)X = 0.5 µm / 200 mm(rotary-type detector)Y = 0.5 µm / 50 mm; 2 µm / 800 mm (standard)Y = 0.7 µm / 50 mm; 3 µm / 800 mm(long-type detector)Y = 0.7 µm / 50 mm; 3 µm / 800 mm(rotary-type detector) |
| Скорость движения | CNC mode: max. 200 mm/sJoystick mode: 0 - 50 mm/s |
| Стандарт | EN ISO, VDA, JIS, ANSI and customize setting |
| Тип удержания детектора (необходимая опция) | Standard Long type Rotary type |
| Траверс | X = 200 mmY = 800 mmZ2 = 500 mm |
