Данные о продукции
| Вывод данных | RS-232C, Digimatic, USB 2 interface |
| Выход | Digimatic, serial, USB2.0 series A (for memory)*1,USB2.0 B Type (for system communication) |
| Индентор/Револьверная головка объектива | Motor driven and manual operation |
| Контроль испытательной силы | Electromagnetic generation of force (force motor) and automatic control (load, duration, unload) |
| Объективный блок линз | Up to 4 pcs. mountable (one mounted 50X as standard) |
| Привод башни | Motor-driven and manual operation |
| Произвольнаяиспытательная сила | up to HV0,05 settable in HV0,001 increments, from HV0,05 settable in HV0,01 increments |
| Разрешение диагональной длины отступа | Objective lens less than 50X: 0.1μm (Objective lens more than 50X: 0.01μm) |
| Стандарт | ISO 6507-2, ISO 4545-2, JIS B 7725 |
| Функции | Calculation of Vickers / Knoop*2 hardness, and ceramic fracture toughness based on IF method (JIS R1697), 3 display format (standard, list, simple), GO/NG judgment, test condition guide, curve and user correction, hardness corresponding value, statistics calculation |
